piaa for drl's

[MONSTERMATT]

which size fits in the drl lights . i am sure there needs to be some cutting but i was wondring what size will fit best if i have to "massage" it, i think it is 540 piaa or 510, i would like to see some pice of A piaa swap, im not refering to the bulb onLy replacement but the whole housing THANKS

[DRTYFN]

Depends on how much of the DRL light bucket you want to trim out. Do you have a Dremel?

This is a list of PIAAs that will fit if the plastic valence is modified(trimmed):
http://www.piaa.com/Lamps/Lamp-pages/510.html
http://www.piaa.com/Lamps/Lamp-pages/600hid.html


Full list of lamps:
http://www.piaa.com/Lamps/Lamps-General.html

[wilfred]

The 510 will fit right in (no trimming required) it is a tad smaller than the original drl so a small gap is there. The grills will fill in the gap perfectly but it blocks the light output a lot so I never put them on. Speaking of light output, I had the ion (fog) ones so they are not all that bright. I would imagine the clears (driving) ones will be brighter.

[ROX]

Wilfred, how did you mount the 510's so they don't wiggle out of the hole?

[wilfred]

They are only mounted on the plastic valance, not the metal bumper. All I had to do was to flip the piaa mounting bolt facing the back and drill a hole or enlarge an existing hole, can't remember exactly as it has been a few years. Only on very bumpy roads like offroading at night, you will notice them bouncing a little bit. But absolutely no problems on streets or highways. Like I said, it's been on for couple years and never had I need to adjust them or anything, they are on tight so no wiggle.

[twenty2]

I also mounteed the 510's, but the driving lights. I minimized the bouncing with washers on both sides of the mounting holes.

[MONSTERMATT]

cool deal, much appreciated, any good ideas on where i can score the 510 for a fair price

[twenty2]

Originally Posted by MONSTERMATT

cool deal, much appreciated, any good ideas on where i can score the 510 for a fair price

nothing better than e-bay for a 150.00 or less. Some stores out here have them for 250.00 on up.

[Sportsdude]

Originally Posted by MONSTERMATT

which size fits in the drl lights . i am sure there needs to be some cutting but i was wondring what size will fit best if i have to "massage" it, i think it is 540 piaa or 510, i would like to see some pice of A piaa swap, im not refering to the bulb onLy replacement but the whole housing THANKS

PIAA 600 is nice but expensive.

[MONSTERMATT]

Can I get a pic of the 510 with the grills in? THANKS
