10-30-2004, 04:07 PM
|
|
Hummer Veteran
|
|
Join Date: Dec 2003
Location: Newnan, GA (transplanted Texan)
Posts: 82
|
|
Klaus/PartsGuy,
Any luck on locating and installing the TNR? I cant seem to locate it for purchase via the 15120706 p#
__________________
Yellow 03 Adventure w/black Grill, UM8 Touch Screen Navigation Radio, U2K XM Digital Radio, Remote 6-CD Changer, JBA Titanium Headers, Corsa Off-Road Sport, Airaid Filter & MIT, Nology Wires & Plugs, S&P Pro-Flash, Warn 9.5ti w/X-Line, Toyo Open Country M/T 37x13.5.
|
10-30-2004, 04:07 PM
|
|
Hummer Veteran
|
|
Join Date: Dec 2003
Location: Newnan, GA (transplanted Texan)
Posts: 82
|
|
Klaus/PartsGuy,
Any luck on locating and installing the TNR? I cant seem to locate it for purchase via the 15120706 p#
__________________
Yellow 03 Adventure w/black Grill, UM8 Touch Screen Navigation Radio, U2K XM Digital Radio, Remote 6-CD Changer, JBA Titanium Headers, Corsa Off-Road Sport, Airaid Filter & MIT, Nology Wires & Plugs, S&P Pro-Flash, Warn 9.5ti w/X-Line, Toyo Open Country M/T 37x13.5.
|
11-15-2004, 09:58 PM
|
 |
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
2
|
10-30-2004, 05:24 PM
|
|
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
Bevo,
Do NOT buy part number 15120706 for your 2003 H2. That part number is for the 2005 (and possibly late 2004) H2s. I am working on this now.
The Bose amps were changed in mid 2004 to a lower grade model. 2003s have the "LUX" amp, just like the Cadillac Escalades. The later 2004s and the 2005s have the "premium" Bose system. You can tell the difference my the audio selections available on your radio. If your audio selections include "Normal, Driver, Rear, and Spacious" you have the "LUX" amp. If your selections include "Custom" you have the "premium" amp.
This is important, as the 2005 Hummer has the "premium" amp. The TNR for the "premium" amp vehicles appears to be different than for the "LUX" amp vehicles. Picking the wrong combination appears to not work (no audio).
The 2005 Escalade appears to have the TNR and "LUX" amp combination.
|
11-25-2004, 03:04 PM
|
|
Hummer Veteran
|
|
Join Date: Jul 2003
Location: Fredericksburg, Virginia, USA
Posts: 142
|
|
Great. You have a PM.
Happy Thanksgiving.
Got it. Looks great Klaus.
Wendell
__________________
03 H2 Pewter W/Lux, with 05 Navigation Radio and XM added. (Sold)
07 H3 Slate Blue W/Lux, Off-Road, NAV, Sunroof, XM, Tow, Auto (Sold)
08 H2 White W/Lux, NAV, Air Sup.
|
11-02-2004, 06:48 PM
|
|
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
Well, the TNR was delivered! They shipped it overnight.
Time to take the truck apart again this weekend!
|
11-02-2004, 12:14 AM
|
|
|
|
Join Date: Jun 2003
Posts: 7
|
|
If you guys want something realy cool, I just converted my "05" TNR unit to operate with my rear view backup camera (automatic when car is put into reverse) as well as hooked it up to my DVD player, damn good quality video screen too, suprised the **** out of me, I thought it would only be so,so video, but its great. There are a couple of people making and installing units, but this one is the "real deal"
http://www.navwithtv.com/ |
10-30-2004, 07:21 PM
|
 |
Banned
|
|
Join Date: Jan 2003
Posts: 24,247
|
|
Ok, thanks. I didn't realize the difference when I was trying to look it up.
|
10-30-2004, 07:02 PM
|
|
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
The INR is the 2004 NAV unit (Integrated Navigation Radio - what I have now).
The TNR is the 2005 NAV unit (Touchscreen Navigation Radio)
|
10-30-2004, 04:07 PM
|
|
Hummer Veteran
|
|
Join Date: Dec 2003
Location: Newnan, GA (transplanted Texan)
Posts: 82
|
|
Klaus/PartsGuy,
Any luck on locating and installing the TNR? I cant seem to locate it for purchase via the 15120706 p#
__________________
Yellow 03 Adventure w/black Grill, UM8 Touch Screen Navigation Radio, U2K XM Digital Radio, Remote 6-CD Changer, JBA Titanium Headers, Corsa Off-Road Sport, Airaid Filter & MIT, Nology Wires & Plugs, S&P Pro-Flash, Warn 9.5ti w/X-Line, Toyo Open Country M/T 37x13.5.
|
01-10-2005, 10:39 PM
|
|
|
|
Join Date: Apr 2004
Posts: 103
|
|
Hi,
I have the 04-H2 Non-Lux amp.
i have 6 cd changer and i want to replace it with the 03 or 04 DVD screen navigator from the dealer. I am not using the on-start service, So i want to add the 6 CD Changer from the Escalade in the OnStar location.
I like to know also if the new 05-Navigator has DVD feature, if not, which one is the latest and suitable DVD navigator to buy.
I need to know what parts i need and how to do it.
I remember that i saw in this forum someone did this installation but i wasn't able to find it again.
Any help, pls ?
Elie
__________________
H2: We Civilized The Beast
|
11-15-2004, 10:00 PM
|
|
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
6
|
11-22-2004, 06:14 PM
|
|
Hummer Veteran
|
|
Join Date: Jul 2003
Location: Fredericksburg, Virginia, USA
Posts: 142
|
|
I just called the Hummer dealer in Richmond and asked if they could get the TNR, PN 10377531 for my 03 H2. He says the part number is not any good. Since this is the number that most are using, what gives? Is this guy just wrong? Or is there a GM Delco distributor that I should try.
Thanks,
Wendell
__________________
03 H2 Pewter W/Lux, with 05 Navigation Radio and XM added. (Sold)
07 H3 Slate Blue W/Lux, Off-Road, NAV, Sunroof, XM, Tow, Auto (Sold)
08 H2 White W/Lux, NAV, Air Sup.
|
11-20-2004, 12:59 AM
|
|
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
Correct. No 2003s came with Navigation, 2004s came with the INR (joystick) Navigation, and the 2005s come with the TNRs.
You should really insist on knowing the part number of the NAV unit in question.
It appears that Cadillac Escalades all have the LUX Amp. HOWEVER - Verify the part number before buying!
|
11-23-2004, 06:34 PM
|
|
|
|
Join Date: Nov 2004
Location: Tennessee
Posts: 45
|
|
Klaus, When you installed TNR did you happen to take any pics of the VSS and the pin out/in on instrument cluster or do you have the info for that if you hooked it up and did the wire come with it ?
|
11-17-2004, 10:51 AM
|
|
|
Klaus how did you hook up xm? Do you have a GM tuner or an aftermarket one?
|
11-15-2004, 10:02 PM
|
|
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
8
|
01-11-2005, 03:23 AM
|
|
|
|
Join Date: Aug 2003
Location: \"Lost Wages\"
Posts: 1,150
|
|
Just do a find for Nav and Klaus. He's about covered all the basis on Nav/cd/xm including p/n's, etc.
__________________
Jonahs
|
11-23-2004, 06:05 PM
|
|
Hummer Veteran
|
|
Join Date: Jul 2003
Location: Fredericksburg, Virginia, USA
Posts: 142
|
|
Thanks Klaus,
I was able to order the TNR from Model without to many problems. It is on back order now, but should be in to them in the next day or two.
They said the did not carry the XM module or the disc. I called Specmo and they say only dealers can get those items. I will be at the Hummer dealer near me tomorrow and will talk to them about getting the XM module and disc. Any other thoughts? Thanks, Wendell
__________________
03 H2 Pewter W/Lux, with 05 Navigation Radio and XM added. (Sold)
07 H3 Slate Blue W/Lux, Off-Road, NAV, Sunroof, XM, Tow, Auto (Sold)
08 H2 White W/Lux, NAV, Air Sup.
|
10-31-2004, 02:25 PM
|
|
Hummer Guru
|
|
Join Date: Nov 2002
Location: CSA
Posts: 2,511
|
|
Bevo,
Those part numbers look good. HOWEVER - I have not done the TNR yet. No guarantees!
You still need to buy the GPS antenna for the NAV.
I can't recommend the 2005 antenna for XM. The wiring/connectors are completely different between the 2003 and 2005 H2s. Besides, the XM kit comes with an XM antenna. If your 2003 has a sunroof, you might want to use an aftermarket magnetic/stick-on XM antenna. They are not very expensive. The other option would be to buy and install the 2005 AM/FM antenna, and mount the antenna from the XM kit where the 2003 factory AM/FM antenna is located on the roof.
I'm not aware of any GM MP3 player, but they might exist.
|
